fischer DuoPower 8 x 40 Universal Wall Plug

Name: fischer DuoPower 8 x 40 Universal Wall Plug
Brand: fischer

Product variants

Download of image data

Top Features

Combination of two material components for more performance.
Secure functions for solid (expansion) and hollow and panel building materials (folding/knotting).
Easy installation: narrow edge of the plug prevents it from falling deeper into the drill hole.
Best possible feedback from the anchor - you can feel that the anchor is sitting perfectly.

The Duo of power and intelligence

Advantages

Two component materials for top load values and intelligent functioning depending on the substrate.
Great feedback (feel-good factor) of the plug. You can feel exactly when the plug is installed perfectly.
The narrow plug rim prevents slipping into the drill hole.
The serrated anti-rotation feature prevents rotation in the drill hole during installation.

The fischer DuoPower is an intelligent 2-component plug with three product functions. The intelligent universal plug is suitable for fixing in all building materials. This allows a variety of applications with just one plug. The fischer DuoPower adjusts itself automatically to the building material and transfers the highest loads through the three product functions of folding, expanding and knotting. The very good feedback from the plug when screwing the screw in generates extra security. The fischer DuoPower 6 x 50, 8 x 65 and 10 x 80, because of the larger anchorage depth, are particularly suitable for fixings in hollow building materials, aerated concrete and for bridge plaster.

Applications

Light shelves
Light mirror cabinets
Curtain rails
Hanging baskets
Electrical installations
Wall clocks

Building materials

Concrete
Solid brick
Solid sand-lime brick
Aerated concrete
Vertically perforated brick
Perforated sand-lime brick
Plasterboard
Gypsum plasterboard and gypsum fibreboards
Hollow blocks made from lightweight concrete
Cavity floor slabs made from bricks and concrete or similar
Natural stone
Chipboard
Solid panel made from gypsum
Solid brick made from lightweight concrete

You can find detailed information on building materials in the registration document.

Functionality

The DuoPower is suitable for pre-positioned and push-through installation.
The duo of two different materials and its multiple functional abilities (expanding, folding, and knotting) extend the range of applications to additional materials with top loads.
The required screw length is given by the plug length + fixture thickness + 1 x the screw diameter.
Suitable for wood and chipboard screws, as well as stud screws.
In the case of fixing boards, the threadless part of the screw must not be longer than the fixture.

Mounting Strip 1 Picture

1 / 4

Mounting Strip 2 Picture

1 / 5

Mounting Strip 3 Picture

1 / 4

Drill diameter ( d₀ )	8 mm
Min. drill hole depth ( h₁ )	50 mm
Min. panel thickness ( d_p )	12,5 mm
Anchor length ( l )	40 mm
Min. bolt penetration ( l_E,min )	45 mm
Max. load in concrete	110 kg
Max. load in solid brick	62 kg
Max. load in vertically perforated brick	25 kg
Max. load in aerated concrete	10 kg
Max. load in gypsum plasterboard 12.5 mm	15 kg
Amount	125 pcs
Packaging	Bio Bag
GTIN (EAN-Code)	4048962319934
